ID # 17203724

Bauma Light TRL620D Mini Track Loader

Call for Price

Mini Track Loader

The Baumalight tracked mini skidsteer is manufactured in Ontario Canada and powered with a Kubota diesel engine, the Baumalight Compact utility track loader is a Mini Skidsteer designed to easily navigate through tight spaces and good productivity on the tools. The hydrostatic drive is set up with true joystick controls with hydraulic pilot lines just like large skidsteers have. The remote hydraulic pump system with case drain delivers hydraulic flow that can be set to maximum engine capacity and the standard self-levelling bucket reduces spills and provides extra control when loading and unloading material. The Baumalight all metal frame mini track loader also features durable rubber tracks that can handle uneven or rough terrain, and ride-on platform for improved visibility while maneuvering through confined areas.

A three-pump hydraulic operating system is used, one for hydraulic flow to run the machine’s auxiliary & boom and two pumps for the propulsion systems, one for each drive motor. There is also a dedicated oil cooler to better manage hydraulic heat generation and the lift cylinders are cushioned at the end of stroke.

TRL620D Mini Track Loader
Sale Type
Bauma Light
QC Generators outlets

Hydraulic Float

The hydraulic float feature allows the operator to gently skim the attachment along the contour of the surface without down pressure or lift.

QC Generators outlets

Operating Capacity

The WRL58G model has an operating capacity of 665 lbs (35% of tip capacity) and 760 lbs (35% of tip capacity) with added weight kit.

QC Generators outlets

Dual Joystick Controls

The dual joystick control system allows you to easily operate the drive system and the boom at the same time.

QC Generators outlets

Aux Pressure Gauge and 12V Plug

The dashboard has a convenient auxiliary pressure gauge and a 12V plug.

QC Generators outlets

Standard Case Drain

Sometimes referred to as a third line, the case drain line will relieve any excess pressure and drain it back to your return line, then into the reservoir.

QC Generators outlets

Ground Speed

The ground speed of the Baumalight Mini Skidsteers is quite impressive with the wheeled model able to reach 7.84 km/h.

QC Generators outlets

Honda Gas Engine

The WRL58G model is powered by a reliable 22.1 HP (688cc) Honda GX690 gas engine.

QC Generators outlets

Oversized Radiator

To increase the power and ensure cooler running, the WRL58G has an oversized hydraulic radiator.

QC Generators outlets

High Capacity Fuel Tank

The high capacity fuel tank holds 12.5L of fuel allowing you to work longer.

QC Generators outlets

Double Piston Pump Driven

Both sides of the Mini Skidsteer is driven by a dedicated dual piston hydraulic pump.

QC Generators outlets

Ground Clearance

The WRL58G has a ground clearance of 8 inches.

QC Generators outlets

Boom Safety Lock Bar

When you need to perform maintenance, the boom safety lock bar allows you to raise the boom and engage the locking bar. How you can safety stand under the raised boom without risk of the boom dropping.

QC Generators outlets

Full Stand-in Operator Compartment

For a safer and more comfortable operation, the operator compartment allows you to fully stand inside.

QC Generators outlets

Optional Self-Levelling Valve

The self-levelling valve makes sure the load remains level to the ground while you’re raising the boom.

QC Generators outlets

Parts Compartment

This handy storage compartment gives you easy access to spare parts.

QC Generators outlets Protected Light

The front lighting system is securely encased in a metal frame to keep it protected from damage.

QC Generators outlets

Heavy Duty Boom

The boom arms are constructed with ¾” thick steel plates.

QC Generators outlets

Grease Pins on all Pivot Points

The Mini Skidsteer features grease pins on all pivot points, reducing the risk of equipment damage and providing long life and easy servicing.

QC Generators outlets

Hardened Steel Bushings

Spring Bushings made from high grade chrome-vanadium AISI 6150 spring steel on all main pivot points.

QC Generators outlets

Crating Option

Baumalight will ship your mini skidsteer crated upon request.


specifications – comparison chart


Engine Hp 24.5 HP
Engine Type Diesel
Fuel tank size 40L
Engine Brand D1105 Kubota
Drive type Hydrostatic
Drive control Joy stick
Carriage Tracks
Travel Speed 4.57 Km/h | 249.89 ft/min
Ground weight (without weight kit) 4 per sq. in
Releif setting (psi) 3,000
GPM under no load 10.5
Number of pumps 3
Boom control Joy stick
Self Leveling yes
Width (without bucket) 40"
Ground clearance 6.5"
Length (without bucket) 70"
Pin heights 76"
Tipping (lifting) front edge of bucket 1,600 lbs
Same as above with weight kit 1,730 lbs
Tipping (lifting) without any attachment 3,190 lbs
Same as above with weight kit 3,500 lbs
Unit weight without bucket 2,930 lbs
Same as above with weight kit 3,170 lbs
