DR Power DR Portable Generator PRO XL17500P

  • DR Power DR Portable Generator PRO XL17500P
  • DR Power DR Portable Generator PRO XL17500P
  • DR Power DR Portable Generator PRO XL17500P
  • DR Power DR Portable Generator PRO XL17500P
  • DR Power DR Portable Generator PRO XL17500P
  • DR Power DR Portable Generator PRO XL17500P
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview
 Maximum Power! You won't find a more powerful portable generator available anywhere. The PRO XL17500P can start and run a 5-ton air conditioning unit and can power up to 16 circuits. Capable of providing backup power for most, or all, of your home.
A Power Producing Workhorse!

With 17500 Watts, this unit has enough power to provide substantial back up during a power outage or to run a host of tools and machinery on your jobsite. Its big, electric-starting, 992cc DR OHVI gasoline engine and a 16-gallon fuel tank let you run it for up to ten hours at a stretch (at 50% load) before refueling.

The PRO XL17500P is equipped with heavy-duty pneumatic wheels that make it possible to maneuver manually around a jobsite. An integrated lifting eye provides an attachment point for moving mechanically or loading/unloading into a truck or trailer. An hour meter is included for tracking maintenance intervals.

PREMIER 2200i Control Panel Control Panel on the 17500


1. Idle Control Switch

2. Hour Meter

3. (1) 50A 2P Circuit Breaker

4. (1) 12VDC 10A Outlet

5. (1) 125/250V 14-50R Outlet

6. (1) 125/250V 30A L14-30R Twist Lock Outlet

7. (4) 30A 1P Circuit Breakers

8. (2) 120V L5-30R 30A Twist Lock Outlets

9. (1) 120V 20A 5-20R GFCI Duplex Outlet

10. (1) 120V 20A 5-20R Duplex Outlet

11. (2) 20A 1P Circuit Breakers




Specifications
Model
DR Portable Generator PRO XL17500P
Category Name
Generators
Year
2021
Sale Type
New
Manufacturer
DR Power
Wheel
12.3 in. Pneumatic
Height
39.5 in.
Length
48.5 in.
Weight
390 lbs.
Frequency
60 Hz
Fuel Type
Gasoline
RPM Speeds
3600
Engine Type
OHV
Lubrication
Oil Pump
Fuel Capacity
16 gallons
Wattage Range
17,500 - 26,250
Number Of Tires
2
Shipping Weight
513 lbs.
Generator Voltage
120/240 VAC
Shipping Dimensions
50 in. x 23 in. x 44.25 in.
features
Self-Feeding

DR 992cc OHVI ENGINE

features full pressure lubrication with automotive style spin-on oil filter to promote long engine life. Low pressure oil shutdown protects engine from damage. Electric-Starting (battery included).
DR POWER EZ DIAL POWER GRADER
LARGE-CAPACITY FUEL TANK

(16 gallons) produces extended runtimes of up to ten hours (at 50% load). Includes a fuel gauge so you can time refueling intervals without guesswork.


DR POWER EZ DIAL POWER GRADER
RUGGED STEEL FRAME

protects the generator and engine and provides a durable structure for lifting and maneuvering.


DR POWER EZ DIAL POWER GRADER
HEAVY-DUTY PNEUMATIC WHEELS

for maneuvering in and out of storage or around a job site.


DR POWER EZ DIAL POWER GRADER
INTEGRATED LIFTING EYE

for easy transport and security on the jobsite.
